8

PART

ONE

SPECIFICATIONS

Electrical Requirements:

Rated Current Input:
Sound Level:
Altitude:

*Oxygen Output

Concentration Levels:

Maximum Outlet Pressure:

120 VAC +10% (132 VAC/108 VAC),

60 Hz
4.3 A
50 dB Average

Up to 6,000 ft. (1828 meters) above sea level

without degradation of concentration levels.

From 6,000 ft. (1828 meters) to 13,129 ft.

(4000 meters) below 90% efficiency.

ALL 5LXO2/5LX MODELS

95.6% to 87% at 1/2 to 5 L/min.

* Stated concentration levels

achieved after initial warm-up period

(approximately 30 minutes).

5 + 0.5 psi.

(34.5 + 3.45 kPa.)

SPECIFICATIONS

5LXO

2

INDICATORS:

O

2

Purity

SYSTEM FAILURE

Below 73%

73% to 85%

SYSTEM OKAY

Over 85%

Indicator Lights

RED - Continuous Audible

Alarm Sieve-GARD

Compressor Shutdown

YELLOW

GREEN

O

2

Label

Symbol

5LX INDICATORS:

Status

SYSTEM FAILURE

SYSTEM OKAY

Indicator Lights

RED

Label

Symbol

I/O

GREEN
