Page 56

PART

TWO

TRANSPORTING THE COMPRESSOR

(FIGURE 1)

WARNING

NEVER transport a compressor with a cylinder connected

to or stored on the compressor, otherwise injury or

damage can occur.

CAUTION

When transporting the compressor, be careful not to

bump the compressor or the connectors into obstacles.

Otherwise damage to the compressor may occur.

There are two (2) methods to safely transport the compressor:
A. ONE HAND - Grasp the handle at the bottom rear of the

compressor.

B. TWO HANDS - Grasp the hand grips on the sides of the

compressor.

INITIAL SETUP

PROCEDURE 2

Hand Grip

Handle

Hand Grip

FIGURE 1 - TRANSPORTING THE COMPRESSOR
