7.
When
installing
a
new
microprocessor 2 ,
loosen
the
black
cover
3 that
protects
the
gold
contacts
on
the
microprocessor,
but
do
not
remove
it.
Use
the
vacuum
pen
1
to
pick
up
the
new
microprocessor
then
completely
remove
the
black
cover.
* X
XXX
XXX
XX*
8.
Position
the
microprocessor
so
that
the
notches
1
on
the
microprocessor
are
aligned
with
the
tabs
in
the
microprocessor
socket.
Important
To
avoid
damaging
the
microprocessor
contacts,
do
not
tilt
the
microprocessor
when
installing
it
into
the
socket.
* X
XXX
XXX
XX*
9.
Use
the
vacuum
pen
to
lower
the
microprocessor
straight
down
into
the
system
board
socket.
10
Hardware
Removal
and
Replacement
Guide
