42
DB-25 AUDIO INPUT & BYPASS MODE
A/V CINEMA SCALER PRO - DB-25 AUDIO BYPASS MODE
The A/V Cinema Scaler Pro can accept high quality 8 channel analog audio via
the DB-25 input located on the back panel. This input is only accessible from the
bypass mode. The audio through this input will be directly passed to the analog
DB-25 output.
ENABLING BYPASS MODE
To enable the bypass mode, locate the bypass mode button on the front panel.
From the Main Screen press the Bypass button on the front panel to enable the
bypass mode. The bypass mode will cycle in the following order. Each button
press will progress to the next option.
Please note that there will be NO VIDEO OUTPUT when using the bypass
function.
Main Screen
Analog DB-25
Input
