English
9
M1405 SERIES USER’S MANUAL
# Icon Item Description
1 Webcam
Webcam for video
communication.
2 Microphone
Internal microphone for sound
recording.
3 LCD Display Displays computer output.
4 Speakers
Left and right speakers deliver
stereo audio.
5 Keyboard
For entering data into your
computer.
6 Touchpad
Touch-sensitive pointing device
which functions like a computer
mouse.
7 Click Buttons
The left and right buttons function
like the left and right mouse
buttons.
8
Fingerprint
Reader
Fingerprint scanner for added
system security.
9
a). Smart Setup
b). Smart Manager
a). During the off mode, press
“+SMART” button to enter “Smart
Setup” menu. You can choose
BIOS Setup Utility, System
Recovery, and other functions in
this setup menu.
b). In the Windows operating
system, press “+SMART” button
to initiate “Smart Manager”.
10 Power Button Turns the computer on and off.
2.4 LED Indicators
These LED lights show that stats of certain system components and
their activity.
# Icon Item Description
1 Num Lock LED
Indicates the computer’s embedded
numeric keyboard status for numeric
data input.
2 Cap Lock LED Indicates the computer’s input are all
capital letters.
3
WWAN Status
LED
Indicates when the WWAN device
is active. (WWAN module may be
optional)
4
Bluetooth
Status LED
Indicates when the Bluetooth device is
active. (Bluetooth may be optional)
5
Wireless LAN
Status LED
Indicates when the WiFi LAN device is
active.
6
HDD Status
LED
Indicates when the hard disk drive is
active.
7
Battery Status
LED
Flash when charging, and off when
the battery is full.
8
Power Status
LED
Indicates the computer’s power status.
