14
Armor
Vinyl sheath
Core
S=1.5 mm
=1.56mm
DPYCYS-1.5 sectional view
Armor
Vinyl sheath
Shield
2
Shield
2
Several cables are required to supply at local. In this manual, JIS (Japan Industrial Standard )
cables are specified. Use equipment cables refering to the figures below.
Sheath
JIS Cables (Cross section)
Sheath
Armor
Vinyl sheath
Shield
Sheath
Core
S=2.5 mm
=2.01mm
Core
S=1.5 mm
=1.56mm
2
DPYCYS-2.5 sectional view
TPYCYS-1.5 sectional view
