3–6 SCANTEAM 5700 User’s Guide
Keyboard Style
This programming selection allows you to program the scanner to support
special keyboard features, such as CAPS LOCK, SHIFT LOCK, Data Entry, and
CTRL+ codes. These special keyboard features are shown in the chart below.
Default = Style A.
Style A
[ ASCII function codes (00–1F) are sent to the terminal via a “CTRL+” sequence
(i.e., ‘CR’=CTRL+M)
(If terminal is not listed, then no secondary type keyboard is supported.)
Style B Style C Style D
IBM PC/XT XT CAPS LOCK
Keyboard Style
Terminal
SHIFT LOCK
Style E
Gr DOS SHIFT LOCK
IBM PC/AT AT CAPS LOCK SHIFT LOCK “CTRL” + ASCII [ Gr DOS SHIFT LOCK
IBM PS2 (50–80) NORM CAPS LOCK SHIFT LOCK Gr DOS SHIFT LOCK
HDS 2000, 3200 T/W “CTRL +”
IBM 3180 (122 Key) T/W D/E
COMTERM 6178 T/W D/E
TELEX (88 Key) T/W D/E
SIEMENS 9758 NORM CAPS LOCK
NCR 7052 34Key 56 Key 122 Key Caps On 122 Key Caps Off
“CTRL” + ASCII [
“CTRL” + ASCII [
DEC Norm “CTRL +” MAKE / BREAK
Style B Style C
✱
Style A
Style D Style E
Note: The Keyboard Style Table below applies the SCANTEAM 5700 software
prior to software revision level 2.0.
Keyboard Style Selections
