English –
9
Throttle and Choke lever Rider 11
The engine speed is adjusted with the throttle
control, and thereby also the rotation speed of the
blades.
The control is also used to activate the choke
function. When the choke is used the engine
receives a richer mixture of fuel and air, which
simplifies cold start.
PRESENTATION
Brake pedal / Parking brake Rider 11
The brake pedal activates a disc brake which is
placed on the gearbox and brakes the drive wheels.
When braking the clutch pedal should also be
pushed down to achieve best braking power.
The brake pedal also operates as a parking brake if
the lock button is pressed in when the pedal is
pressed.
Clutch pedal Rider 11
The clutch pedal disengages the engine and stops
forward movement.
The blades are
not affected by the clutch pedal.
