HearthStone
Quality Home Heating Products Inc ®
Tribute Model 8040
8
C
LEARANCES
T
O
C
OMBUSTIBLES
Clearances may only be reduced by means approved by the regulatory authority.
It is very important to follow minimum clearances for chimney connectors to combustibles such as walls
and ceilings when installing the stove near non-combustible surfaces.
B
C
E
A
G
D
H
K
J
H
I
Tribute Clearances
Parallel
Corner
Clearances (inches)
A
B C D
E
G
H
I
J
K
Single wall stove pipe without heat shield
16.5
19
21
24
27.5
13
17
25.5
28.5
68.25
Single wall stove pipe with heat shield
16.5
14.5
16.5
19.5
27.5
13
11
19.5
22.5
59.75
Double wall stove pipe with heat shield
16.5
8
10 13
27.5
13
7
15.5
18.5
54
