1
Please check if the power receptacle has good earthing
condition before using to guarantee your safety.
Warning sign
Names of the parts
Meaning and description of the symbols
Forbidding sign
Contents marked with that symbol are related
to the safety of the product and the personal
safety of the users. Please operate in strict
conformity to the contents, otherwise it may
cause damage of the machine or injure the
personal safety of the user.
Contents marked with that symbol are actions
forbidden to perform. Performing of those
actions may result in damage of the machine
or injure the personal safety of the user.
Control panel seat
Lint filter
Inner tub
Attachment block
Cabinet
Fixed leg
(3 pieces)
Adjustable leg
Detergent box
Top lid component
Inner cover component
Pulsator
Water inlet
valve
Water absorption
cushion
Front control board
Back cover
Power line
Adjustable foot
seam
Filter cover
Drain hose
Hang hole of
drain hose
Handle
Base
Liquid whitener inlet
Liquid whitener inlet
Notes: All illustrations in this Manual are given for reference only. Your products
and accessories may show differences from these illustrations due to our
continuous improvement.
