Washing sequence
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Spin timer
SPIN WASH
Wash timer
WASH TIMER
Wash selector Buzzer Water-filling entrance
(To set to below 2 minutes,
first set to 5 minutes then
turn it back. it can increase
the service life of the timer).
(standard current,
strong current)
(The buzzer will ring when
the washing finishes)
(to set to below 1 minute,
first set to 2 minutes then
turn it back. it can increase
the service life of the timer).
Water-filling selector
Wash
DRAIN
DRAIN
STRONG
STRONG
STANDARD
STANDARD
WASH SELECTOR
WASH SELECTOR
1.Water-filling selector
Set the water inlet selector at the "WASH" side.
(Figure 1)
2. Fill the water and add the dissolved washing
powder to make the water level reach the preset
position. (Figure 2)
Run washing program for some time to stir and
dissolve the powder completely.
3.Put in the laundries. If the water quantity is
insufficient, please add water.
4.Select the current.
Select the strength of the current according to
the laundries. (Figure 3)
5.Select the washing time
Select the washing time according to the laundries.
(Figure 4)
6.After washing, the buzzer will ring. Set the "WASH
SELECTOR" at "DRAIN". (Figure 5).
8
SPIN TIMER SPIN TIMER
WASH TIMER WASH SELECTOR WASH SELECTOR
12
9
6
3
15
OFF SILK
WOOL
COTTON
LINEN
STANDARD
STRONG
4
3
2
1
5
OFF
SILK
WOOL
OFF
MAX
BUZZER BUZZER
DRAIN DRAIN
12
9
6
3
15
OFF
SILK
WOOL
COTTON
LINEN
