Heat & Glo • EM-415/EM-415H • 31317 Rev Q • 10/06 45
Service Parts List
36 in. Energy Master Circulating Fireplace
Service Parts
EM-415 SERIES
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
# Description of Part EM-415 EM-415H Qty.
Refractory Retainer 11847 11847 3
1 Traditional Brick Back Refractory - pre 34/98 29245 1
1 Traditional Brick Back Refractory - post 34/98 29992 1
2 Traditional Brick Hearth Refractory - pre 34/98 29244 1
2 Traditional Brick Hearth Refractory - post 34/98 29993 1
3 Traditional Brick Side Refractory 28393 2
4 Herringbone Brick Back Refractory 4010-016 1
5 Herringbone Brick Hearth Refractory 4010-019 1
6 Herringbone Brick Side Refractory - Right 4010-013 1
7 Herringbone Brick Side Refractory - Left 4010-014 1
Firescreen Rod 12052 12052 2
8 Firescreen Assembly 28417 28417 2
Firescreen Ring 11857B 11857B 7/8
Firescreen Handle 4021-149 4021-149 1
9 Top Standoff 13433 13433 4
10 Drywall Flange 29238 29238 1
Door Track 15425 15425 1
Door Pivot Clip 31527 31527 2
Strip Protector 18320 18320 2
11 8 in. Starter Section Assembly 22069B 22069B 1
Junction Box Cover Plate 26548 26548 3
Junction Box Kit JK9 JK9 1
12 Junction Box 21878 21878 1
Romex Connector 32536 32536 1
Junction Box Installation Instructions 31166 31166 1
13 Hearth Filler 30331 30331 1
14 Smoke Shield 31191 31191 1
Smoke Diverter 30559 30559 1
Damper Repair Kit 4010-001 4010-001 1
Nailing Flange 31190 31190 4
15 Hood 31682 31682 1
16 Grate GR23 GR23 1
17 Lower Grille Assembly 31679 31679 1
18 Upper Grille Assembly 31696 31696 1
Installation Pack 31699 31699 1
Velcro Strips 17439A,17440A 17439A,17440A 2ea
Installation Instructions and Owner’s Manual 31317 31317 1
Exterior Touch-up Paint 71479 71479 1
Herringbone Brick Refractory option available week 03/04. 1
