Heat & Glo • EM-415/EM-415H • 31317 Rev Q • 10/06 37
12 12
Reference Materials
A. Fireplace Dimensions
36 in.
(914mm)
23-3/8 in.
(594 mm)
8-1/8 in.
(206 mm)
10-1/2 in.
(267 mm)
dia.
4-1/4 in.
(108 mm)
9-5/8 in.
(244 mm)
8-5/8 in.
(219 mm)
13-1/2 in.
(343 mm)
Gas Knockout
Outside
Air 9-1/4 in.
(235 mm)
41-1/4 in.
(1048 mm)
(effective height)
7-1/2 in.
(191 mm)
13-1/2 in.
(343 mm)
4-1/4 in.
(108 mm)
9-1/4 in.
(235 mm)
41-3/8 in.
(1051 mm)
Gas Knockout
Junction
Box
3-7/8 in.
(92 mm)
28-1/4 in.
(718 mm)
14-1/8 in.
(359 mm)
42 in.
(1067 mm)
8-3/4 in.
(222 mm)
22-3/4 in.
(578 mm)
