Before Using Before Using
1. The height of the drain hose shall be
less than 10cm, or the drainage will not
be smooth, and cost such long time that
the machine may stop at mid way.
2. Do not ramp or press the drain hose.
3. If the drain hose is too long, cut it at mid
point. To make smooth drainage, cut the
front end of the hose slantingly.
4. If extra drain hose is needed, please
make separate purchase. The inner
diameter of the extra hose shall not
less than 30mm, and the length shall
not exceed 1.5m.
1.Lean the machine down gently with the front
surface facing the ground. 3. Extend the drain hose from the left side. Push the
drain hose into the groove with hands.
2. Pull out the drain hose from the groove at the left side.
Back
Front
Soft item
Use groove at
this side after
direction changing
How to change the direction of the drain hose
Usage of the drain hose
The drain hose shall drain smoothly
5.If the extra hose is too long, cut it
either at A or at B point.
