Contents marked with that symbol are related to the safety of the product and the personal
safety of the users. Please operate in strict conformity to the contents, otherwise it may
result in damage of the machine or influence the personal safety of the users.
Contents marked with that symbol are actions forbidden to perform. Performing of those
actions may result in damage of the machine or influence the personal safety of the users.
Accessories
Meaning and description of the symbols
Before Using Before Using
Names of the parts
(one piece)
(one piece)
Water inlet hose
Water inlet hose joint
the end connecting to the washing machine
jointer connecting the water
inlet hose and the water faucet
the end connecting to the water inlet hose jointer
Top lid, I
Detergent box
Lint filter(Installed
by user)
Control panel seat
Inner tub
Control panel film
Pulsator
Cabinet
Lower cabinet
Top lid, II
Adjustable foot
Power cord
Drain hose
Fixing foot
(three)
Water absorption cushion Water inlet valve
Handle
Drain hose hanging hole
Back cover
L i n t f i l t e r
(one piece)
Level meter
