Please install and adjust the machine according to the requirement of the manual.
It is very important to your security and correct operating the machine.
Before Using Before Using
Installation and adjustment
Install the lint filter
After opening the package, please take out the
lint filter from the document bag and install it
into the Filter frame of the inner tub. See to the right Figure.
Lint filter
Filter frame
The largest allowed slope of the shank base of the machine is 2 . The slanting or rough ground will result in
unstable running or stoppage of the machine. Please adjust it with following methods:
Confirm it's horizontal
Hang the plumb to confirm it's horizontal
Adjust the Installation position
Adjust the adjustable foot
(1) To twist the adjustable foot at the right front of
the cabinet (front the sight of front), please first
lift up the side of the foot slightly, loosen the
adjustable nut, and twist the foot.
(2) Fasten the nut after adjustment.
Loosen
Fasten
High Low
adjustable nut
adjustable foot
Confirm it's horizontal:
If the bulb of the level meter at the balance display
position is inside the standard circle, it indicates that
the machine is horizontal. Otherwise you need to
a d j u s t t h e a d j u s t a b l e l e g o f t h e m a c h i n e .
Air bubble
Standard circle
Suitable Not suitable
