BENDIX/KING KLN 90B
Page 1-2 10521I05.TDC Rev 5, April/2003
The following labels are received on the EFIS 429 receiver inputs (Pins 4 and 5 of P901):
TABLE 3-1 EFIS 429 Receiver Inputs
The following labels are received on the Radar Graphics 429 receiver inputs (Pins 6 and 7 of
P901):
TABLE 3-2 Radar Graphics 429 Receiver Inputs
The following labels are received by the KLN 90B on the Air Data 429 receiver inputs (Pins 8 and
9 of P901):
TABLE 3-3 Air Data 429 Receiver Inputs
LABEL(OCTAL) DESCRIPTION
100 SELECTED COURSE
306 NAV/WPT/APT LATITUDE
307 NAV/WPT/APT LONGITUDE
314
OR
320 TRUE HEADING
MAGNETIC HEADING
LABEL(OCTAL) DESCRIPTION
306 NAV/WPT/APT LATITUDE
307 NAV/WPT/APT LONGITUDE
LABEL(OCTAL) DESCRIPTION
203 ALTITUDE (1013.25 MB)
204 BARO CORRECTED ALTITUDE
205 MACH
210 TRUE AIRSPEED
211 TOTAL AIR TEMPERATURE
213 STATIC AIR TEMPERATURE
