34
– English
Engine
Cylinder volume, cu.in./cm 3
Cylinder bore, inch/mm
Stroke, inch/mm
Idle speed, rpm
Power, kW /rpm
Ignition system
Manufacture
Type of ignition system
Spark plug
Electrode gap, inch/mm
Fuel and lubrication system
Manufacturer
Carburetor type
Fuel capacity, US Pint/litre
Oil pump capacity at 8500 rpm,
ml/min
Oil capacity, US Pint/litre
Type of oil pump
Weight
Without bar and chain, Lbs/kg
Chain/bar
Recommended bar lengths,
inches/cm
Usable cutting length, inches/cm
Chain speed at max. power, m/sec
Pitch, inch/cm
Thickness of drive link, inch/mm
Number of teeth on drive sprocket
2083 II
4,7/76,5
2,05/52
1,42/36
2 700
4,0/ 9 600
Electrolux
ET
NGK/Champion
BPMR6A/RCJ 7Y
0,02/0,5
Walbro
WJ 77
1,80/0,85
4,0-20,0
0,85/0,4
Automatic
14,9/6,8
15"-28" / 38-71
14"-27" / 36-69
21,4
3/8"/ 9,52
0,058"/1,5
0,050"/1,3
7
TECHNICAL DATA
WARNING! These models of chain saws are capable
of severe kickback that could result in serious
injuries to the user. Do not operate these saws unless
you have extraordinary cutting needs and experience
and specialized training for dealing with kickback.
Saws with significantly reduced kickback potential
are available. Always use the safest saw and cutting
equipment applicable to your cutting need.
! ! ! ! !
The combinations of powerhead, bar and chain have been
investigated in accordance with the vibration requirements of
ANSI B 175.1-1991.
0,058"/1,5 mm S42 S48 988PC 73VL 73LG
0,050"/1,5 mm – – 980PC 72VL 72LG
Note: For the chains above you are free to choose between 0,050"
and 0,058" gauge drive link for the corresponding bar, see the table
below.
Guide bar Saw chain
Length Pitch Max nose
inch inch radius
16-28 3/8 11T Jonsered S42 / S48 or
Total / Sabre 988PC or
Oregon 73VL / 73LG
Recommended original and replacement
bar and chain combinations
The Jonsered saw model 2083 II is in the ANSI categogory of saws
above 3,8 cu. in. and is not
required to comply with low kickback
performance requirements. However, for the Jonsered saw model
2083 II we recommend the following cutting equipment.
