September 1, 2008 7033-277F Page 4
3100 Wood Stove Series (ACC) R
Pedestal (only) Assembly, Step Top Model 70-01
2 Pedestal Base, Millennium Model 70-16
3 Pedestal Riser, Millennium Model 7033-207
Rear Channel Assembly 7033-002
Rope, Door, /4” x 84”, field cut to size 82-1680
47 Screws, Glass Frame, tabs are not required Qty 1: 220-0490
Qty 10: 82-0860
Snap Disc, F125 F-20, Convection Blower 230-0470
Speed Control Only 842-070
14 Spring Handle, Burn Rate Control, 1/4”, Gold 82-060
14 Spring Handle, Burn Rate Control,1/4”, Nickel 250-840
32 Spring Handle, Door, 1/2”, Gold 82-0620
32 Spring Handle, Door, 1/2”, Nickel 250-80
49 Timer Air Control Assembly SRV70-052
10 Timer Arm Assembly 7033-034
9 Timer, Mechanical SRV480-1940
42 Trim Ring, Door, Gold 40-2682
42 Trim Ring, Door, Nickel 430-5340
1 Trim, Oak Strips for Pedestal (2) 82-0560
19 Tube Channel Access Cover (Top) 7033-237
20 Tube Channel Assembly (Manifold Tubes) SRV70-02
28 Tube Support Rack 70-148
41 Washer, Spacing (Door Handle) Qty 1: 222-0010
Qty : 82-0990
Wire Harness for Blower & Snap Disc 7033-262
ITEM # SERVICE PARTS PART NO.
