3100 Wood Stove Series (ACC)
R
IMPORTANT:
THIS IS DATED INFORMATION. When requesting a part for your appliance, please
supply serial number and model name/number to ensure correct service parts. All parts may be ordered
from an authorized dealer.
B. Service Parts & Accessories
ITEM #
ACCESSORIES
PART NO.
Blower Assembly
BK-ACC
1
Door Assembly, Black
82-1092
1
Door Assembly, Gold Trim
82-1912
1
Door Assembly, Nickel Trim
DR-1/4NL
Leg Kit & Ash Removal System, Cast Legs
LEG-14-BK
Leg Kit & Ash Removal System, Gold Legs
LEG-14-GD
Leg Kit & Ash Removal System, Nickel Legs
LEG-14-NL
35
Legs, Queen Anne, Matte Black
81-1240
35
Legs, Queen Anne, Nickel
LEGS-QANL
35
Legs, Queen Anne, Gold
81-1250
Outside Air Kit, Floor & Rear (Termination Cap, Wire Ties, Flex Adapter, Fasteners) OAK-ACC
see pg 14
Outside Air Back Cover Plate & Sealing Rope, (1 inch x 4 ft) Floor Only
SRV70-041
Pedestal Assembly & Ash Removal System
PED-14
Upgrade to Nickel Door (includes Nickel Spring Handles, Hinge Pins And Logo)
UK-DRNL
ITEM #
SERVICE PARTS
PART NO.
26
Air Channel Assembly, Rear
7033-002
21
Air Channel, Convection
70-144
6
Air Control Rod Guide, Start-Up Air
70-210
37
Ash Pan, Front Assembly, Leg, Step-Top Model
70-008
Ash Pan, Pedestal, Step Top Model
70-010
Ash Pan, Leg, Step-Top Model
7033-050
33
Baffle, Fiberboard (2 pieces), 9-1/2” wide X 1-/4” high
SRV70-209
Blower (Motor Only) Replacement
812-4900
29
Blanket, Ceramic 1/2” thick, field cut to size, 19” wide x 1-/4” high
82-90
Blower Control Box with Switch
7000-194
8,52
Bracket, Leg Mount, Left & Right (Set), Step-Top Model
SRV70-18
Bracket, Snap Disc
7033-036
Brick, Individual
82-0550
34
Brick, Retainer
70-149
27
Brick, Set, Millennium
SRV70-006
50
Brick, Set, Step-Top Model
SRV70-02
Brick, Uncut, (Set of 6)
82-040
1
Burn Rate Air Control Assembly
7033-033
44
Cam Latch (Door Handle)
40-1141
Channel, Ash Removal System, Step Top Model
70-172
Component Pack, Millennium Model, Black and Gold, (includes Touch-up Paint,
Gold Spring Handles, Trimount Plug, Owner’s Manual, Warranty Card)
7033-027
