Hunter Fan ARCHITECT 90061 - Manual (Page 3)

E
9
5
Pop out the first wiring access slug. Use second if needed. Insert the strain relief into the housing and
secure with the washer.
Position the correct depth mark at the bottom edge of the
joist based on the thickness of your sheetrock.
7
G
8
F
Remove the motor/blower from the housing.
New Construction - attaching to joist
H
E
3
B
C
10
Choose Installation Option
For New Construction - attaching to joist go to step A11, page 5
For New Construction - suspended between joists go to step B11, page 8
For Existing Construction - accessible from above go to step C11, page 11
For Existing Construction - accessible only from below go to step D11, page 14
E
A11
5/8
1/2
5/8
1/2
A12
Remove the pre-loaded screw tip covers.
Remove the wiring cover screw. Screw pre-loaded screws into joist or framing.
6
Back out the pre-loaded screw tips until flush
with the side of the housing.
Remove the wiring cover.
Remove packing material.
4
4
5 41721-01 12/25/2004 41721-01 12/25/2004
