27
TRACTOR - - MODEL NUMBER LT16542 (96013001900), PRODUCT NO. 960 13 00-19
SCHEMATIC
BATTERY
FUSE AMMETER
(OPTIONAL)
RED RED
RED
RED
WHITE
BLACK
BLUE
BLACK
BLACK
BLACK/WHITE
BLACK
BLUE
BLUE
BLACK
BLACK
GRAY
GRAY
BLACK
SOLENOID
M A
STARTER
CLUTCH / BRAKE
(PEDAL UP)
SEAT SWITCH
(NOT OCCUPIED)
IGNITION
UNIT
HOUR
METER
FUEL
LINE
FUEL SHUT-OFF
SOLENOID
S
M B
G A1
A2 L
REVERSE SWITCH
SPARK PLUGS
GAP
(2 PLUGS
ON TWIN CYL. ENGINES)
(OPTIONAL)
NOT IN REVERSE
SHORTING CONNECTOR
ATTACHMENT CLUTCH
(CLUTCH OFF)
REMOVABLE
CONNECTIONS
NOTE
YOUR TRACTOR IS
EQUIPPED WITH A SPECIAL
ALTERNATOR SYSTEM.
THE LIGHTS ARE NOT
CONNECTED TO THE
BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE.
BECAUSE OF THIS, THE
BRIGHTNESS OF THE LIGHTS
WILL CHANGE WITH ENGINE
SPEED. AT IDLE THE LIGHTS
WILL DIM. AS THE ENGINE IS
SPEEDED UP, THE LIGHTS
WILL BECOME THEIR BRIGHTEST.
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED CLIPS
WERE REMOVED FOR SERVICING OF
UNIT, THEY SHOULD BE REPLACED
TO PROPERLY SECURE YOUR WIRING.
IGNITION SWITCH
CIRCUIT POSITION
OFF
B+A1 RUN/OVERRIDE
B + S + A1 START
M+G+A1
B+A1 RUN
“MAKE”
L+A2
NON-REMOVABLE
CONNECTIONS
LIGHTING SYSTEM OUTPUT
5 AMP AC @ 3600 RPM
ALTERNATOR DIODE
28 VOLTS AC MIN. @ 3600 RPM
(CHARGING SYSTEM DISCONNECTED) CHARGING SYSTEM OUTPUT
3 AMP DC @ 3600 RPM
03059_197428
03059
(IF SO EQUIPPED)
LIGHT
SWITCH
BROWN BLACK
HEADLIGHTS
