HP recommends Microsoft ® Windows ® XP Professional for mobile computing.
Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.
© 2003, 2004 Hewlett-Packard Development Company, L.P. The information contained herein is subject to
change without notice. The only warranties for HP products and services are set forth in the express warranty
statements accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
5982-1149ENUC, Rev. 2, 02/27/2004
For more information visit our website at www.hp.com
Product number HP product
L1575A HP Digital Projector xp8010
L1576A HP Digital Projector xp8020
Service and support
Web support www.hp.com
Phone support 1-800 HP Invent (1-800-474-6836)
Accessories
L1578A Lens ultra wide angle 1:67:1 to 2.0:1
L1580A Lens long throw 2.4:1 to 2.88:1
L1581A Advanced connectivity module
L1582A 250-watt comp P-VIP projector lamp (xp8010)
L1583A 300-watt comp P-VIP projector lamp (xp8020)
L1584A Soft carry case
L1585A Hard carry case
L1586A Remote control, Wireless (IR) Smart (included)
L1590A Ceiling mount
L1640A 802.11b Compact Flash wireless card
L1642A Cable extended IR receiver
L1645A Gyration Ultra Pro Suite
L1646A Gyration RF remote control
L1682A Remote Access management software
Cables
L1514A Cable, VGA/USB to M1-DA, 6-ft
L1529A Cable, M1-DA to DVI/USB, 6-ft
L1588A Cable, M1-DA to SCART, 6-ft
L1589A Cable, M1-DA to BNC, 6-ft
Environmental ranges
Operating temperatures: 50 to 104° F (10 to 40° C)
Storage temperatures: -4 to 140° F (-20 to 60° C)
Power requirements 100–120V, 200–240V at 50–60H
Power consumption
Maximum: 400 watts (xp8010), 450 watts (xp8020)
Power certification
Safety certifications: USA (UL950, FDA—remote controller); Canada (CSA 22.2 #60950)
Electromagnetic compatibility: USA (FCC Part 15 Class B, RF - FCC part 15 C),
Canada: (ICES-003 Class B)
Warranty: 3-year warranty
Ordering information
Brightness
Resolution
Image contrast
Lamp life
Weight
Projected image size
Throw distance
Display technology
Resolutions supported through scaling
Projector lens
Keystone correction
Noise level
Video capability
Lamp type
Audio
Audio/video composite input
Signal interface
Resizing of images to full screen
Detection of computer signal input
Image synchronization
Remote control
Mounting capability
Control interface
Environmental humidity
Dimensions (l x w x h)
What’s in the box
3100 lumens, 3750 lumens in grayscale
1000 to 1
13.4 lb
300 watt P-VIP lamp
HP Digital Projector xp8020; AC 3 conductor power cord, 10-foot; VGA cable;
cable shroud; wireless remote control with mouse function and laser pointer;
multi-language User’s Guide (CD-ROM); multi-language Quick Start card; 2 batteries;
hanging lens cap; warranty card
HP Digital Projector xp8000 Series
HP Digital Projector xp8010 (Product number: L1575A) HP Digital Projector xp8020 (Product number: L1576A) Technical specifications
2600 lumens, 3600 lumens in grayscale
1024 x 768 True XGA
800 to 1
1,500 hours average
13.2 lb
Approximately 31 to 347 in
Approximately 3 to 37 ft
Texas Instruments DLP ™
VGA (640x350) through UXGA (1600x1200)
Standard 2.0–2.4:1, optional short-throw: 1.67:1–2.0:1; long-throw: 2.4:1–2.88:1
Horizontal ±17°, vertical ±40°
32 dB(A) ± 2 dB(A) peak
S-video, composite, component, HDTV (up to 1080i)
250 watt P-VIP lamp
Two 5-watt
Digital Graphics (M1-AD: provides VGA, DVI, component - all with USB - and SCART), two VGA input (15 D-sub), S-video input (mini-DIN),
composite video input (RCA), component video input (RCA), analog video graphics input (BNC), switched audio inputs (mini phone plug), switched audio inputs (RCA);
AV outputs: VGA output (15 D-sub), audio output (RCA); connectivity: LAN (RJ45), RS232 (9 D-sub), switched 12V power control (barrel),
wired remote (mini phone), IR-remote front and rear, steel-backed Kensington lock slot
15-pin VGA input connector, YPbPr RCA jack (green/red/blue), video RCA jack (yellow), audio RCA jack (red/white), 3.5 mm stereo mini jack, S-video connector,
UART mini-DIN 8-pin connector, output: B-type USB terminal for mouse port, 15-pin VGA output connector
Automatic
Automatic
Automatic
Wireless remote controller with USB mouse function and laser pointer
Ceiling, tripod and tabletop mountable
RS232
80% RH max, 50 to 104° F (10 to 40° C)
17.4 x 12 x 5.5 in
HP Digital Projector xp8010; AC 3 conductor power cord, 10-foot; VGA cable;
cable shroud; wireless remote control with mouse function and laser pointer;
multi-language User’s Guide (CD-ROM); multi-language Quick Start card; 2 batteries;
hanging lens cap; warranty card
