TROUBLE SHOOTING
Error messages
There are two types of error messages that can appear
on the display:
• Service messages - These messages do not
represent any direct danger for the operator or the
machine.
• Warnings - These warn of faults or safety defects
that can cause mechanical damage.
All error messages that have been acknowledged re-
main as small yellow red warning triangles in the fi eld
for service and can be accessed by bringing up the
service menu and selecting ’Warnings”. The messages
are listed in order of priority, highest priority fi rst.
When a fault that has in some way restricted the ma-
chine’s functions ceases, a message appears on the
display. This message must be acknowledged for the
machine to return to full functionality.
Service messages
When a service message appears on the display, the
operator is made aware of it through the work light
fl ashing three times.
The service message remains on the display until the
operator has acknowledged it. The message disap-
pears from the display and is replaced by a yellow
warning triangle in the fi eld for service. The triangle
symbol remains for as long as the message is current.
Service messages and actions
Service message Action
Oil temperature is
above T
high1
Oil temperature is above 80°C
(176°F). Put the machine into
circular pumping mode to
cool the hydraulic fl uid.
Oil fi lter needs to be
changed Change the oil fi lter at once.
Low battery Approx. 30 mins operating
time left. Charge the battery.
Warnings
When an error message appears on the display, the
operator is made aware of it through the work light
fl ashing continuously. The machine is put into idling
mode in connection with the warning. If the message
is not acknowledged the horn sounds and the motor is
turned off.
The operator acknowledges the warning message by
selecting override. The light stops fl ashing and the mes-
sage disappears from the display and is replaced by a
red warning triangle in the fi eld for service. The triangle
symbol remains for as long as the message is current.
In override mode, certain machine functions can be
used up to 50%. This function is available in order to
move the machine away from hazardous environments.
Warning messages and actions
Warning message Action
Oil temperature above
T
high2
Oil temp. over 90°C
(194°F). Put the machine
into circular pumping mode
to cool the hydraulic fl uid.
Oil temperature below
T
low
Oil temp. below 10°C
(50°F). Warm the machine
up to 40°C (104°F) before
starting work.
Phase Error Voltage too high or out of
phase. Check incoming
voltage.
Motor Over
Temperature
The motor decreases to
half-speed due to overheat-
ing. Normal operation can
be resumed when the tem-
perature has normalized.
NO OIL PRESSURE Fault in the phase rotation
relay resulting in motor and
pump running in the wrong
direction. Check that the
motor is running in the right
direction. If the problem
persists, contact service.
IDLE PRESSURE TOO
HIGH The oil pressure does not
fall when the machine is put
into circular pumping mode.
Fault in the pump-around
valve. Contact service.
Emergency stop/machine stop
If the machine stop on the remote control or the
emergency stop on the machine are pressed or if the
function does not work, a message will appear in the
display at start up. Check and confi rm the message.
If you are still unable to start the machine, contact the
service department.
If the message has not been confi rmed within 10
seconds the horn will sound together with the fl ashing
light.
