PAGE 1
This unit is available as a 6 station configuration.
Designed for residential and light commercial
applications, this controller has four separate programs
with up to sixteen possible start times a day. This
ensures efficient watering of different garden or turf
areas.
These different areas may require individual watering
programs and often use different types of sprinklers.
Examples: Turf areas generally use pop-up sprinklers
and require less frequent but heavier watering. However,
flower beds use micro sprays and require more frequent
watering. The valves (stations) which water similar
garden areas are often grouped together and put into the
same program as they need to be watered on the same
days.
These stations (valves) will water in sequential order
from the lowest number at the start time (or times)
nominated and on the days selected. Maximum watering
duration for a station (valve) is 12 hours and 59 minutes.
This controller has three types of watering day options.
Either, interval watering from everyday to every 15th day,
individual day selection per program, or a 365 day
calendar for ODD/EVEN day watering.
An innovative feature of this controller is the Rain Sensor
Ready (RSR) technology. This allows individual stations
to be controlled by a rain sensor. In this way, garden
areas that are subject to rain, can have their irrigation
suspended during wet periods, while areas under cover
can continue to be watered.
Features
Features 1
Glossary 2
Programming Instructions
Introduction
3
Programming Example 4
Other Functions 5
General tips for programming 5
Programming
Set Current Time & Correct Day
6
Set Calendar (Optional) 6
Step 1. Set Start Times 7
Step 2. Set Watering Days 8
Interval Day Selection 8
Individual Day Selection 8
Odd / Even Day Selection 9
Step 3. Set Station Run Times 9-10
Manual Operations
System test facility
11
Run A Single Station 11
Run A Program 12
Other Features
Stop
12
Stacking Start Times 12
Automatic BackUp Program 12
Rain Sensor Ready 13-15
Rain Off Mode 16
Water Budgeting 16
Installation Instructions
Mounting The Controller
17
Electrical Hook-Up 17
Field Wiring Connections 18
Terminal Block Layout 18
Power Supply Connections 19
Connection Of Valves 19
Pump Hook-Up Connections 20
Electrical Characteristics 21
Servicing The Controller 22
Fault Finding Guide 23
Spare Watering Planners 24-25
Table Of Contents
