For technical questions, please call 1-800-444-3353.

SKU 6510

aSSemBlY

The 10” Bench Grinder requires

minor assembly. The assembly

instructions below are written for the

left side but the right side is identical.

Refer to the Parts List, at the back

of this manual, for the individual part

numbers.

tool rest assembly

Bolt the BENCH GRINDER UNIT (1)

to a stable workplace.

tool rest

knob (8)

tool

rest

(7)

FiGure 1 – removing the tool rest knob

2. Facing the front of the BENCH

GRINDER UNIT, remove the front

TOOL REST KNOB, and loosen the

rear TOOL REST KNOB (8) as in

Figure 1.

tool rest

knob (8)

tool

rest

(7)

FiGure 2 – moving tool rest

3. Pivot the tool rest down and forward

so that it is in a horizontal position

and replace the front TOOL REST

KNOB as shown in Figure 2.
Adjust the TOOL REST (7) to the

desired distance from the GRINDER

WHEEL (2). In no circumstances

should the TOOL REST be clos-

er than 1/8” from the GRINDER

WHEEL.
Tighten both TOOL REST KNOBS.

eye Shield assembly

Bolts

(15)

eye

Shield

(3)

Washers

(17)

nuts (16)

FiGure 3 –

attaching the eye Shields

and eye Supports

1. Attach the EYE SHIELDS (3) to

the SHIELD SUPPORTS (4) using

BOLTS (15), NUTS (16), and WASH-

ERS (17) as shown in Figure 3.
