4
Installation and adjustment
The largest allowed slope of the
shank base of the machine is 2
.
The slanting or rough ground will
result in unstable running or
stoppage of the machine. Please
adjust it with following methods:
Adjust the adjustable foot:
Adjust the installation position
Please install and adjust the machine according to the requirement of the manual. It is
very important to your security and correct operating the machine.
1.To twist the adjustable foot, please
first lift up the side of the foot slightly,
loosen the adjustable nut, and twist
the foot.
2.Fasten the nut after adjustment.
Loosen Fasten
High Low
adjustable nut
adjustable foot
Install the bottom plate Install the lint filter
1.Press downward to
assmble.
2.Pull upward to detach.
Pull down
Put up
After you open the package, please lean the
washing machine gently down on soft items
( like the towel cloth, blanket, etc. ). Install the
bottom plate to the bottom of the machine with
the five screws by a cross screwdriver, then l
ift the machine up gently. See to the figure:
Back
Front
Bottom plate
Screw
Soft items
