POWER
ON
/
OFF
START
PAUSE
RESERVE
PROGRAM
Reserve(hours later)
XQB50-20
NORMAL
MEMORY
Fuzzy
ON/OFF button
Press the ON/OFF button to switch on the power
After the power is on,another press will switch off the power.
After the power is on, if not press the START/PAUSE button,
the washing machine will be shut-off 5 minutes later
automatically. During the transmitting, it displays "--"
During the process of reserve, it displays reserve time(hours)
No.16
Indicator light of RESERVE and TIME REMAINED
RESERVE button WATER LEVEL button
JEAN
COTTON
FIBRE
START/PAUSE button
After the power is on,press the START/PAUSE button,
tha washing machine will start
Pressing the button in running will cause pausing.
In pausing, press it again to restart
NORMAL
PROGRAM button
The following automatical program are available.
Programs Application
Press the knob and you
can seslect 2-24h reserve
end time.
When the RESERVE
starts, press and hold the
knob, it will display
the reserve mode.
MEMORY
The washing machine can check laundries automatically.
After laundries
the level can be set automatically. The
auto-set water level are "4","6","8","10".
You can select water level by yourself. After the washing
machine started working, it will not set the water level
again,you must press the ON/OFF button to set again.
If there is water remained in the tub, it can not perform
laundries check, and will display water level "6". If you put
wet laundries, it may display "10".
If you select "Fast" program, the water level will
be set to "2" automatically. When it is reached, then
machine will inlet water along with washing, and the "4"
indicator flashes, till "4" is reached. Then it stops inlet
water, display "4",and perform normal washing.
During the WASH and RINSE program, press the
WATER LEVEL to supply water, till you loose hand or
the water reaches the overflow level, it stops supplying water.
QUICK
GENTLE
NORMAL Normal washing and spinning gently
Memory and usage of the self-edit program
10 minutes fast washing
For woolen or underpants
For clothes made from fibre
For bigger and thicker clothes
For cotton clothes
Normal washing
The GENTLE SPIN program cooperates with the NORMAL
and GENTLE program in washing.
QUICK
GENTLE
FIBRE
JEAN
COTTON GENTLE-SPIN
Using process Using process
If there are abnormal phenomenon, it displays abnormal signal.
When the program starts, it displays time remained(minutes).When the total
time exceeds 99 minutes, if "A " represents 100 minutes, "b " represents
110 minutes, then A3 equals 103 minutes.
GENTLE SPIN
GENTLE SPIN
