Meaning and description of the symbols
Honorable users,
Thanks for your choosing Haier products.
Haier products integrate high-tech, precision frontier science and possess the best quality
among simila r products. To facilitate your operation, please read the manual carefully and
operate this machine according to it.
Haier's star-level service is always accompanying you. No matter what problems you meet
in use please do not hesitate to contact us by the telephone number and address on the
certificate of warranty. We are at your service all the time.
Thanks again for your choosing and introducing Haier products.
Haier-sincere forever!
Before Using Before Using
Names of the parts
the end connecting to
the water inlet hose jointer
the end connecting to
the washing machine
jointer connecting the
water inlet hose and
the water faucet
Warning sign
Forbidding sign
Contents marked with that symbol
are related to the safety of the
product and the personal safety
of the users. Please operate in
strictconformity to the contents,
otherwise it may cause damage
of the machine or injure the
personal safety of the user.
Contents marked with that symbol
are actions forbidden to perform.
Performing of those actions may
result in damage of the machine
or injure the personal safety of
the user.
Accessories
bottom plate
(one)
water inlet hose
(one)
Water inlet
hose jointer
(one)
ST4X16
tapping screws
(8 purchase)
Top lid
Control panel
seat
lint filter
Inner tub
Pulsator
Control panel
film
Cabinet
Cabinet,lower Adjustable foot
Power cord
Hook
Drain
hose
Handle
Back cover Fixed foot(3 pcs)
Water level knob Water inlet valve
Adjustable foot
seam
Water-absorption
gasket
