SKU 92386 for technical questions, please call 1-800-444-3353. Page 19
SAW blADe
(4)
OuTSIDe flANge (5)
NuT (6)
fIgure p
blADe guArD
(12)
rOTATION ArrOW
cAuTION! When necessary, wear heavy duty gloves to avoid accidental
cuts to hands and fingers.
With one Wrench (70), hold the Motor Arbor firmly in place while, with the other
Wrench (71) provided, unscrew and remove the Nut (6). Next, remove the Outside
Flange (5). Then, remove the old Saw Blade (4).
(See figures p and Q.)
4.
5.
WreNcH
(70)
WreNcH
(71)
SAW blADe
(4)
INSIDe flANge (3)
(DO NOT remOVe)
fIgure Q
