Page 35
60GB 1.5G SATA 5.4K
Up to 8
1-8
Smart Array E200 Controller
Smart Array P400 Controller
Smart Array P600 Controller
NOTE: Optional mixed PCI-X/E required for SA-P600.
External Storage
Quantity
Supported
Position
Supported
Host Controller or Adapter
Modular Smart Array 20
Family
1 per SCSI
VHDCI connector
External
Smart Array 6402/128 Controller
Smart Array 6404/256 Controller
NOTE: Optional mixed PCI-X/E cage required.
Modular Smart Array 50
Enclosure
2 per connector
(supports 1+1
cascading)
External
HP Smart Array P600 Controller
NOTE: Optional mixed PCI-X/E cage required.
Modular Smart Array 500
G2
1 per SCSI
External
Please see the Modular Smart Array 500 or 500 G2 QuickSpecs
for the latest list of supported HBAs:
Modular Smart Array 1000:
(Worldwide)
Modular Smart Array 1500 cs:
Maximum Storage Capacity - (with MSA50)
Internal
576GB (8 x 72GB SAS SFF)
External
1.44TB (20 x 72GB SAS SFF)
Total
1.728TB (4 x 72GB int. + 20 x 72GB ext.)
Tape Drives, Tape Autoloaders, & Tape Libraries
NOTE: For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the following:
NOTE: For an up-to-date listing of the latest O/S Support details for each of the Tape Autoloaders & Tape Libraries listed below,
please see the following:
NOTE: For complete listing of tape drive offerings see
For recommended tape drive offerings for this ProLiant server see the following:
Quantity
Supported
Position
Supported Controller
HP StorageWorks Tape
Drives, External
DAT 24 USB
DAT 40 USB
DAT 72 USB
1
External
USB 2.0 Port
QuickSpecs
HP ProLiant DL380 Generation 5
Storage
DA - 12477 Worldwide QuickSpecs — Version 1 — 6/26/2006
Page 35
