September 1, 2008 250-6422E Page 37
Castile Pellet Stove
B. Component Locations
Cleaning Rods
TERMINA L BLOC K
CENTER 2 SCREWS FOR
THERMOS TA T WIRE S
POWER OUTLET
FUSE
Fuse
Red Call Light is
located on top of
unction Box behind
the Control Box.
Control Box
acuum Switc h
Convection Blower Housing
Combustion
Blower Feed Motor
High
Med
Low
Heat utput Switch
Reset Button
Reset
Button
10 Heat Exchanger Tubes
Figure 37.1
Figure 37.2
Figure 37.3
