B19 b20 – Hunter Fan ASHBURY 81003 User Manual
Page 9
41937-01 10/26/2010
9
H
B18
H
B19
B20
I
Reinstall the motor by inserting the tabs and pushing
up into position. Make sure the wires are not pinched
between the motor and the housing.
Connect wiring harness. DO NOT ALLOW THE MOTOR TO
HANG FROM THE WIRING HARNESS.
Secure the motor by tightening the 2 screws.
A
3 Pin
2 Pin
Fan Motor
Light
Light
Green
Black
Black
White
Black
Black
White
White
Bare Copper
Ground
B16
Main Switch 1 (AC In)
Switch 2 (AC In)
*Option Fan & Main Light Together
*Option
Connect wires as shown.
F
B17
G
Install the wiring cover plate.
