Hustler Turf 3700 User Manual
Page 34
_0910
7-9
Blower Assembly (544510)
NOTES:
1. Assemble bearings in spindle housing with extended race to the inside.
INDEX
NO.
PART NO.
QTY.
DESCRIPTION
1
078378
4
CS .50-20 X 1.50 HX G5 ZN
2
017046
12
LW .50 MEDIUM SPRING ZN
3
078386
4
FW .510 X 1.750 X .180 ZN
4
301267
2
DRIVE PULLEY
5
324327
1
BLOWER TOP
6
077123
2
BEARING W/O COLLAR
7
022582
1
CAST SPINDLE HOUSING
8
758565
1
IMPELLER 11”
9
758730
1
JACK SHAFT
10
212472
4
KEY
11
045765
5
FW 1.030 X 1.50 X .134 ZN
12
705194
4
CS .50-13 X .750 HX G5 ZN
13
034272
6
NT .312-18 HX G5 ZN
14
768523
6
FW .343 X .687 X .051/.080 HD ZN
15
324319
1
BLOWER HOUSING
16
074252
2
CS .50-13 X 1.50 HX G5 ZN
17
263517
2
BEARING DISK
18
324343
1
UPPER IDLER ARM
19
068759
6
CW .560 X 1.340 X .050 PN
20
023317
2
NT .50-13 UNT LK G5 ZN
21
705178
1
CS .375-16 X 1.750 HX G5 ZN
22
767954
7
FW .406 X .812 X .060 SAE HRD ZN
23
022772
2
FLAT IDLER PULLEY
24
036384
2
SPRING 1/4 COIL PL 1.23
25
259812
2
DECK LIFT SPRING CHAIN
26
520627
1
SPINDLE HOUSING ASSEMBLY
27
016527
4
CS .50-13 X 1.00 HX G5 ZN
28
301317
1
PULLEY
29
324293
1
LOWER IDLER ARM
30
705731
1
CS .375-16 X 2.750 G5 ZN
31
324350
1
IDLER SPACER
32
054502
1
NT .375-16 HX G5 ZN
33
079194
6
MS .25-20 X .750 TH CR ZN
34
324335
1
BLOWER INLET
35
768515
6
FW .281 X .625 X .051/.080 HD ZN
36
024927
6
NT .25-20 HX G5 ZN
