Peco catcher – Hustler Turf 3700 User Manual

Page 28

background image

_0910

7-3

Peco Catcher

NOTES:

INDEX NO.

PART NO.

QTY.

DESCRIPTION

1

PECC0041

1

BOX TOP

2

PECC0039

1

SCREEN SUPPORT

3

PECB8001

1

SCREEN

4

PECC0043

1

BOX RIGHT SIDE

5

PECC0045

1

BOX BACK

6

PECC1184

1

FILL GAUGE

7

PECC0044

1

BOX LEFT SIDE

8

PECC0042

1

BOX BOTTOM

9

PECA0331

1

BOX OPENING FRAME

10

PECK1435

2

ADJUSTING SCREW

11

PECK1422

2

ADJUSTING NUT

12

PECB1596

2

DOOR LINKAGE

13

PECK1418

2

LINKAGE PIN

14

PECK1437

4

RUE_RING COTTER PIN

15

PECV1154

1

PLASTIC DOOR

16

PECB1834

1

UPPER DOOR MEMBER

17

PECA0330

1

DOOR FRAME ASSEMBLY

18

602210

1

DECAL SERIAL NUMBER
