_0910

7-5

Peco Catcher

NOTES:

INDEX NO.

PART NO.

QTY.

DESCRIPTION

19

PECB1833

1

BOX BASE FRAME

20

PECB0007

1

HANDLE MOUNT

21

PECJ0552

1

HANDLE GRIP

22

PECA0329

1

HANDLE ASSEMBLY

23

PECB0006

1

HANDLE SLIDE BRACKET

24

PECB1835

1

PIVOT PLATE

25

PECB1832

2

PIVOT BRACKETS

26

PECB1840

1

LATCH ROD

27

PECJ0255

1

LATCH SPRING

28

PECJ0234

1

3/8" BALL JOINT

29

PECB1804

1

LATCH HOOK

30

PECK1410

1

3/8" NUT

31

PECS0155

1

PIVOT BUSHING

32

PECB1805

1

LATCH HOOK PIVOT PLATE
