English – 35
TECHNICAL DATA
Recommended original and replacement bar and chain combinations
Following is a list of recommended cutting equipment for the Husqvarna chain saw model 55 Rancher. The combinations of power
head, bar and chain have been investigated in accordance with the kickback and vibration requirements of ANSI B 175.1–2000.
The guide bar nose radius is determined by either the maximum number of teeth in the nose sprocket or the corresponding
maximum nose radius of a solid bar.
The following list is the chain saw manufacturers recommendations. There may be other combinations available, which will also
achieve kickback reduction.
As we are listing the maximum guide bar nose radius, you may use a guide bar with smaller nose radius than in our list. For guide
bars of the same length, all sprocket-nose guide bars of the same pitch and having the same number of sprocket teeth may be
considered to have equivalent kickback energy. A hard nose bar having the same length and nose radius as a sprocket-nose bar
may be considered to have equivalent or less kickback energy than the sprocket-nose bar.
Low kickback saw chain is a chain which has only met the kickback performance requirements of ANSI B 175.1 safety requirements
for gasoline powered chain saws when tested on the representative sample of chain saws below 3.8 cu. in. specified in ANSI 175.1.
We recommend that you as a replacement use the listed chains or "Low kickback saw chains" which are available at your dealer.
Note: For the chains above you are free to choose between 0,050" and 0,058" gauge drive link for the corresponding bar, see the
table below.
Bar Chain
Length, inches Pitch, inch Max nose radius
13 0,325 10T Husqvarna H30, Oregon 95VP
15 0,325 10T
16 0,325 10T
18 0,325 10T
20 0,325 10T
15 0,325 10T Husqvarna H21 / H25 / S24, Oregon 21LP / 21BP / 34LG / 34SL
16 0,325 10T
18 0,325 10T
20 0,325 10T
18 3/8 11T Husqvarna H81, Oregon 73V
20 3/8 11T
16 3/8 11T Husqvarna H42 / S48, Oregon 73LP / 73LG / 77SL
18 3/8 11T
20 3/8 11T
24 3/8 11T
0,050"/1,3 mm H30/95VP - - 20LP 20BP 33LG 33SL
- H80 - 72LP 72LG 76SL 72V
0,058"/1,5mm - H25/H21 S24 21LP 21BP 34LG 34SL
H42 H81 S48 73LP 73LG 77SL 73V
