Honeywell DR65 - Manual (Page 3)

TrueDRY
™
DR65
NEED HELP? For assistance with this product please visit http://yourhome.honeywell.com
or call Honeywell Customer Care toll-free at 1-800-468-1502.
Read and save these instructions.
® U.S. Registered Trademark. Patents pending. Copyright © 2010 Honeywell International Inc. All rights reserved.
?
TrueDRY™ DR65 Dehumidification System 69-2089EFS—11 1
ABOUT YOUR NEW DEHUMIDIFIER
Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Maintaining Ideal Humidity . . . . . . . . . . . . . . . . . . . 2
Setting the Controls . . . . . . . . . . . . . . . . . . . . . . . . . 3
Control Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INSTALLATION
Install to Fit Your Application . . . . . . . . . . . . . . . . . . 5
Plumbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Terminal Description . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
MAINTENANCE
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Horizontal to Vertical Conversion . . . . . . . . . . . . . 12
Technical Description . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Refrigerant Charging . . . . . . . . . . . . . . . . . . . . . . . 14
Compressor/Capacitor Replacement . . . . . . . . . . 14
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5-Year Limited Warranty . . . . . . . . . . . . . . . . . . . . . 16
• The TrueDRY™ DR65 is designed to be installed indoors in a space that is protected from rain and
flooding.
• Install the unit with space to access the front panel for maintenance and service.
• Avoid directing the discharge air at people, or over the water in pool areas.
• If used near a pool or spa, be certain there is no chance the unit could fall into the water or be splashed,
and that it is plugged into a ground fault interrupt (GFI) outlet.
• To ensure quiet operation, do not place the device directly on the structural supports of the home.
• A drain pan must be placed under the unit if installed above a living area or above an area where water
leakage could cause damage.
