PARTS LIST A
Part # Description Qty. Part # Description Qty.
1A Muffler 1 42A Starting Case Assy. 1
2A Cylinder Head Bolt 4 43A Spiral Spring 1
3A Cylinder Head Cover Bolt 4 44A Starting Wheel 1
4A Cylinder Head Cover 1 45A Circlip 1
5A Lock Nut 2 46A Starting Ratchet 2
6A Adjusting Screw 2 47A Friction Plate Screw 1
7A Rocker Arm 3 48A Cover 1
8A Rocker Arm Bolt 2 49A Starter Pulley 1
9A Valve Push Rod Guiding Board 1 50A Cooling Fan 1
10A Valve Push Rod 2 51A Flywheel Magneto 1
11A Cylinder Head 1 52A Cylinder Block 1
12A Carburetor Shield 1 53A Speed Control Lever 1
13A Carburetor Packing I 1 54A Governor Arm 1
14A Carburetor Assembly 1 55A Governor Spring 1
15A Air Cleaner Case 1 56A Governor Support 1
16A Air Cleaner Seal 1 57A Bolt (M6 x 15) 2
17A Bolt (M6) 4 58A Oil Alert Nut 1
18A Air Cleaner Cover 1 59A Plug (M10 x 15) 2
19A Air Cleaner Element 1 60A Plug Washer 2
20A Air Cleaner Separator 1 61A Oil Alert 1
21A Choke Lever 1 62A Bolt (M6) 2
22A Carburetor Packing II 1 63A Crankshaft 1
23A Stud Bolt (M6 x 109) 2 64A Crankshaft Gear 1
24A Intake Valve 1 65A Oil Dipstick 2
25A Exhaust Valve 1 66A Oil Dipstick Seal Ring 2
26A Cylinder Head Gasket 1 67A Gear Casing 1
27A Exhaust Pipe Stud 2 68A Bolt (M8 x 35) 6
28A Spark Plug 1 69A Gear Case Packing 2
29A Valve Guide 2 70A Bearing 2
30A Valve Spring 2 71A Camshaft Assy. 1
31A Rocker Shaft Circlip 2 72A Locating Pin 4
32A Anti-Wear Valve Stem Protector 2 73A Oil Seal 2
33A Cylinder Head Cover Packing 1 74A Connecting Rod Bolt 2
34A Governor Spring 1 75A Connecting Rod Cap 1
35A Bolt 1 76A Connecting Rod 1
36A High Tension Line 1 77A Piston 1
37A Ignition Coil 1 78A Compression Ring I 1
38A Nut (Special 14mm) 1 79A Compression Ring II 1
39A Starter Ratchet Spring 2 80A Oil Scraper Ring 1
40A Start Rope 1 81A Piston Pin 1
41A Start Handle 1 82A Piston Pin Circlip 2
NOTE: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts.
