APPENDIX PARAMETER CROSS-REFERENCE LIST
24
Code No. Size
Range
Magn.
Contents
L300P
Read/
Write
H033
82
4
0 655.35A
*100
1st No load current Io of motor (Auto)
No
R/WOS
H233
83
4
0 655.35A
*100
2nd No load current Io of motor (Auto)
No
R/WOS
H034
84
4
0.001
9999.000kgm2
*100
1st Inertia J of motor (Auto)
No
R/WOS
H234
85
4
0.001
9999.000kgm2
*100
2nd Inertia J of motor (Auto)
No
R/WOS
A043
86
2
0 50.0%
*10
1st Break point of manual torque boost
R/W
A243
87
2
0 50.0%
*10
2nd Break point of manual torque boost
R/W
A343
88
2
0 50.0%
*10
3rd Break point of manual torque boost
No
R/W
A052
89
2
0 60.00Hz
*100
Frequency of DC braking start
R/WOS
A055
90
2
0 60.0s
*10
Time of DC braking working
R/WOS
A058
91
2
0 60.0s
*10
Time of DC braking working
for beginning of inverter running
R/WOS
A064
92
2
0 10.00Hz
*100
Width of jumping frequency 1
R/WOS
A066
93
2
0 10.00Hz
*100
Width of jumping frequency 2
R/WOS
A068
94
2
0 10.00Hz
*100
Width of jumping frequency 3
R/WOS
A070
95
2
0 60.0s
*10
Time of stopping to accelerate
R/WOS
A073
96
2
0 3600.0s
*10
Integrate (I) gain of PID control
R/W
A074
97
2
0 100.00
*100
Differential (D) gain of PID control
R/W
A075
98
2
0.01 99.99%
*100
Scale of PID control
R/WOS
A086
99
2
0 100.0
*10
Response time of Energy saving function
R/W
b003
101
2
0.3 100.0s
*10
Waiting time of retry
R/WOS
b012
102
2
20.0 120.0
*10
Level of 1st Electronic thermal protection
R/WOS
b212
103
2
20.0 120.0
*10
Level of 2nd Electronic thermal protection
R/WOS
b312
104
2
20.0 120.0
*10
Level of 3rd Electronic thermal protection
No
R/WOS
b015
105
2
0 400Hz
*1
Free electronic thermal frequency 1
R/WOS
b016
106
2
0 1000.0A
*10
Free electronic thermal current 1
R/WOS
b017
107
2
0 400Hz
*1
Free electronic thermal frequency 2
R/WOS
b018
108
2
0 1000.0A
*10
Free electronic thermal current 2
R/WOS
b019
109
2
0 400Hz
*1
Free electronic thermal frequency 3
R/WOS
b020
110
2
0 1000.0A
*10
Free electronic thermal current 3
R/WOS
b100
111
2
0 400Hz
*1
Free V/F control frequency 1
R/WOS
b101
112
2
0.0 800.0V
*10
Free V/F control voltage 1
R/WOS
b102
113
2
0 400Hz
*1
Free V/F control frequency 2
R/WOS
b103
114
2
0.0 800.0V
*10
Free V/F control voltage 2
R/WOS
b104
115
2
0 400Hz
*1
Free V/F control frequency 3
R/WOS
b105
116
2
0.0 800.0V
*10
Free V/F control voltage 3
R/WOS
b106
117
2
0 400Hz
*1
Free V/F control frequency 4
R/WOS
b107
118
2
0.0 800.0V
*10
Free V/F control voltage 4
R/WOS
b108
119
2
0 400Hz
*1
Free V/F control frequency 5
R/WOS
b109
120
2
0.0 800.0V
*10
Free V/F control voltage 5
R/WOS
b110
121
2
0 400Hz
*1
Free V/F control frequency 6
R/WOS
b111
122
2
0.0 800.0V
*10
Free V/F control voltage 6
R/WOS
b112
123
2
0 400Hz
*1
Free V/F control frequency 7
R/WOS
b113
124
2
0.0 800.0V
*10
Free V/F control voltage 7
R/WOS
b022
125
2
50.0 200.0
*10
Level of Overload restriction 1
50.0
150.0
R/WOS
