- Lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV with a 16:9 ratio picture format.
- Note: If a fixed image is displayed on the screen for a long time, it image may become imprinted on the screen and remain visible.
1 Press the ARC button the Aspect Ratio menu appearance on the screen.
2 Press the / button to select the desired picture format.
3 Press the OK button to confirm.
4:3 mode
Choose 4:3 when you want to view a picture with an original 4:3 aspect ratio, with gray bars appearing at both
the left and right sides.
16:9 mode
Choose 16:9 when you want to adjust the picture horizontally, in a linear proportion to fill the entire screen.
Zoom 1
Choose Zoom 1 when you want to view the picture without any alteration. However, the top and bottom portions
of the picture will be cropped.
Zoom 2
Choose Zoom 2 when you want the picture to be altered, both vertically extended and cropped. The picture taking
a halfway trade off between alteration and screen coverage.
Subtitle
when you want to adjust the picture in a non-linear proportion, that is, more enlarged at top sides and no alteration ,
at bottom side.
PANORAMA
Choose PANORAMA when you want to enlarge the picture in correct proportion.
Note: When enlarging or reducing the picture size, the image may become distorted.
Choose Subtitle
Operation
Aspect Ratio Control
Notes
In TV, CVBS1, CVBS1,SVIDEO modes, all screen modes can be selected.
(16:9 Mode . Panorama . Zoom1 . Zoom2 . 4:3 Mode. Subtitle).
In YPbPr, HDMI modes, only 16:9 Mode, 4:3 modes, Zoom1 or Zoom2 can be selected.
In VGA mode, only 16:9 Mode, 4:3 mode, dot by dot can be selected.
In DTV mode, only 16:9 Mode, 4:3 mode can be selected.
24 TFT-LCD TV
