For technical questions, please call 1-800-444-3353.

SKU 68240

Part

Description

Qty.

1

Right Housing

1

2

Lock Button

1

3

Spring

1

4

Gear

1

5

Trigger

1

6

Battery Terminal

1

7

Battery Pack

1

8

Left Housing

1

9

Rubber Damper

2

10

Screw

14

11

Blade Plate

1

12

Screw

9

13

Reciprocating Lever

1

14

Cover Plate

1

15

Roll Pin

2

16

Shaft Housing

2

17

Attachment Bracket

1

Part

Description

Qty.

18

Connecting Bar

1

19

Cotter Pin

1

20

Shaft

1

21

Roll Pin

1

22

Gear

1

23

Washer

1

24

Rivet

2

25

Guard Plate

1

26

Blade Holding Plate

1

27

Blade Clamp Screw

1

28

Circlip

5

29

Gear Housing

1

30

Ball Bearing

1

31

Ball Bearing

1

32

Motor

1

33

Motor Gear

1

34

Shaft

1

Parts List and Assembly Diagram

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM

IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR

MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS

QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE

ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND

LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY

ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS

THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Parts List

Record Product’s Serial Number Here:
Note:
If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only,

and are not available individually as replacement parts.
