NO.
DESCRIPTION PART NO. QTY
ITEM NOTE
1
Engine
533017
1
2
Screw
MU710264
2
3
Speed Control
533013
1
4
Cover, Rear
MU671547
1
5
Screw
70-11-012
1
6
Screw
MU710180
2
7
Adapter, Blade
MU71285
1
8
Strap, Adjuster
MU71318E701
2
9
Washer, Spring
MU710258
6
10
Bolt, Shoulder
MU710184
6
11
Pin, Hair
MU31x10
2
12
Locknut, Flange
MU15x84
9
13
Decal - Hayter Logo
300157
1
14
Nut -M8 Nyloc T’Type
09441
1
15
Decal - Caution
219189
1
16
Bearing, Lifter
MU43788
2
17
Support, Axle
MU671411
2
18
Screw
MU710277
14
19
Index, Height Adjuster
MU71368E701
1
20
Bracket, Handle
MU671317
2
21
Housing (Green)
MU71308
1
22
Decal - Height of Cut
320006
1
23
Serial - no Label
-
1
24
Panel, Front
533090V
1
25
Decal - Warning
331045
2
26
Hub Cap
MU43847
2
27
Wheel, Front (Gray)
MU43724
2
28
Pin, Hair
MU31x9
2
29
Connecting Rod
MU671328
1
30
Front Axle Assembly,
MU671325
1
31
Decal - Engine Stop
331046
1
32
Clip, Front Axle
MU671292
2
33
Screw
MU710274
6
34
Washer, Belleville
MU17x137
2
35
Washer
09276
2
36
Bolt, Hex
MU710201
1
37
Blade
MU671849
1
38
Spacer, Adapter
MU71470
1
39
Cover, Dust
MU643616
2
40
Bolt, Engine
09349
3
41
Spring, Extension
MU710337
1
42
Crossbar Assembly, Rear
MU671315
1
43
Lever, Height Adjuster
MU672278
1
44
Grip, Height Adjuster
MU671297
1
45
Decal - Engine
533006
1
46
Wheel, Rear (Gray)
MU643617
2
47
Washer
MU710252
2
533A PARTS LIST
