Hayter Mowers Double 3 533A - Manual (Page 15)

OPERATING
Remove the rear discharge chute by removing nuts and washers.
Slide the assembly from under the the shoulder bolt (A).
Slide the new side dicharge chute assembly under the shoulder bolt
(A). Then fasten the front and the back of the assembly with the fas-
teners.
To prevent engine overloading and blockages be prepared to make two
cuts in areas of heavy growth. If collection is required, first mow the
area at the maximum height of cut setting with the grassbag fitted.
Reduce the height of cut and mow the area again as necessary until the
required finish is obtained.
To prevent grass damage do not remove more than one third of grass
height in one cut.
When moving the mower across non-grassed areas, stop the cut-
terblade and set the mower to the maximum height of cut to protect the
cutting mechanism.
1.14
THE MOWER
Non-Grassed Areas
Side Discharge
A
A
Heavy Growth
