FRONT PANEL JACKS AND CONNECTIONS
17
1, 2 or 3 is selected using the remote control AVX button. Check the Power On indicator to
make sure the TV is off when not in use.
NOTE:
Model 35TX30B is not equipped with an S-Video on the front input jacks (for
VIDEO:3) 7.
FRONT PANEL JACKS AND CONNECTIONS
• The front panel jacks are provided as a convenience to allow you to easily connect a
camcorder or VCR as shown in tn the following examples.
Front panel jacks and connections illustration
NOTE:
• Completely insert the connection cord plugs when connecting to front panel jacks. If you
do not, the played back picture may appear abnormal.
• If you have an S-VHS VCR, use the S INPUT cable in place of the standard video cable.
• Model 35TX30B is not equipped with front panel S-Video.
