LOCATION OF CONTROLS
16
LOCATION
OF
CONTROLS
Front view illustration
Details are described by the number attached to the part name (example: 1).
1 AVX (Audio/Video) selector
Press this button to select the current antenna source, or video: 1, 2, or 3. Your
selection is shown in the top right corner of the screen.
2 VOLUME level
Press these buttons for your desired sound level. The volume level will be displayed on
the TV screen.
FRONT
PANEL
CONTROLS
CHANNEL selector
Press these buttons until the desired channel appears in the top right corner of the TV
screen.
POWER button
Press this button to turn the TV on or off.
AI (Artificial Intelligence) sensor
This "Artificial Intelligence" sensor will make automatic picture adjustments depending
on the amount of light in the room to give the best picture. See page 33.
REMOTE CONTROL sensor
Point your Genius Remote at this area when selecting channels, adjusting volume, etc.
FRONT INPUT JACKS (for VIDEO:3)
Use these audio/video jacks for a "quick" hook-up from a camcorder or VCR to instantly
view your favorite show or new recording. (Press the AVX button until VIDEO:3 appears
in the top right corner of the TV screen.)
NOTE:
Your Hitachi TV will appear to be turned "off" if there is no video input when VIDEO:
