HOOK-UP CABLES AND CONNECTORS
Most video/audio connections between components can be made with shielded video
and audio cables that have phono connectors. For best performance, video cables
should use 75-Ohm coaxial shielded wire. Cables can be purchased from most stores
that sell audio/video products. Below are illustrations and names of common
connectors.
Before purchasing any cables, be sure of the output and input connector types required
by the various components. Also make sure the cables are the correct length.
300-Ohm Twin Lead Connector "F" Type 75-Ohm Coaxial Antenna
Connector
This outdoor antenna cable must be
For connecting RF signals (antenna or
cable
connected to an antenna adaptor
TV) to the antenna jack on the television.
(300-Ohm to 75-Ohm).
Phono Connector S-Video (Super Video) Connector
Used on all standard video and audio This connector is used on camcorders,
VCRs,
cables which connect to inputs and outputs
and laser disc players with an S-Video
feature
located on the Television's front and rear
in place of the standard video cable to
produce
jack
panels. a high-quality picture.
