19
CASE OPERATION
Narrow Island Frozen Food/Ice Cream Merchandiser
ONIZ - 6’, 8’, 10’ & 12’
1
F = Frozen food, C = Ice cream.
All measurements are taken per CRMA specifications.
F-6’
1
F-8’
F-10’
F-12’
Standard Fans
120 Volts
Amps
0.68
1.02
1.02
1.36
Watts
34
51
51
68
Defrost Heaters
208 Volts
Amps
5.77
7.69
9.62
11.54
Watts
1200
1600
2000
2400
240 Volts
Amps
6.66
8.88
11.10
13.31
Watts
1598
2130
2663
3195
Fans per
Case
2
3
3
4
High Efficiency
Fans
120 Volts
Amps
0.30
0.45
0.45
0.60
Watts
22
33
33
44
Electrical Data
ONIZ
Model
120 Volts
Amps
0.13
0.13
0.13
0.13
Watts
15
15
15
15
Drain
Heaters
Low Temperature Defrost Schedule
No. Per Day
Hours
1
10 pm
2
6 am - 10 pm**
** Or immediately after store closing hour
5
BTUH's/ft listed are for parallel operation. Conventional ratings may be approximated by multiplying listed rating by 1.04.
6
Average discharge air velocity at peak of defrost.
Guidelines & Control Settings
Model
BTUH/ft
5
Evaporator
(
o
F)
Return Air
(
o
F)
Discharge Air Velocity
6
(FPM)
440
500
-12
-22
7
-3
180
180
ONIZ-F
ONIZ-C
Discharge Air
(
o
F)
-2
-13
Superheat Set Point
@ Bulb (
o
F)
3-5
3-5
Electric Defrost
Defrosts
Per Day
2
Model
ONIZ
Fail-safe
(min)
35
Termination
Temp. (°F)
47
Defrost Controls
Timed Off Defrost
Fail-safe
(min)
- - -
Termination
Temp. (°F)
- - -
Hot Gas Defrost
Fail-safe
(min)
20
Termination
Temp. (°F)
60
Reverse Air Defrost
Fail-safe
(min)
- - -
Termination
Temp. (°F)
- - -
Run-Off
Time (min)
13 - 15
C-6’
1
C-8’
C-10’
C-12’
0.68
1.02
1.02
1.36
34
51
51
68
11.54
15.38
16.13
23.08
2400
3200
3355
4800
13.32
17.75
18.65
26.63
3196
4260
4476
6390
2
3
3
4
0.30
0.45
0.45
0.60
22
33
33
44
0.13
0.13
0.13
0.13
15
15
15
15
Anti-Condensate Heater Data
Solid
Front
120 Volts
Amps
0.91
0.86
1.00
1.27
Watts
109
103
120
152
ONIZ-6’
ONIZ-8’
ONIZ-10’
ONIZ-12’
Model
3
Glass cap heater for stainless steel glass cap option only.
4
Data given for one glass wrap-around end.
Glass
Front
120 Volts
Amps
1.69
1.66
1.95
2.35
Watts
203
199
234
282
Glass Front
3
Glass Cap
120 Volts
Amps
0.37
0.42
0.62
0.74
Watts
44
50
74
89
Glass Wrap
4
End
120 Volts
Amps
0.57
0.57
0.57
0.57
Watts
68
68
68
68
Solid Wrap
4
End
120 Volts
Amps
0.26
0.26
0.26
0.26
Watts
31
31
31
31
Lighting Data
Model
2
NOTE: - - - not an option of this case model.
Typical per
Light Row
120 Volts
Amps
- - -
2
- - -
- - -
- - -
Watts
- - -
- - -
- - -
- - -
Maximum
Lighting
120 Volts
Amps
- - -
- - -
- - -
- - -
Watts
- - -
- - -
- - -
- - -
ONIZ-6’
ONIZ-8’
ONIZ-10’
ONIZ-12’
Solid Front
3
Glass Cap
120 Volts
Amps
0.42
0.90
1.20
1.42
Watts
50
108
144
170
