Technical Data
Manual Change Summary
The current revision of this manual includes the
following changes:
Page 12, Parts List:
l The quantity of item 25 (elbow) is changed to 3.
l The quantity of item 47 (elbow) is changed to 1.
Page 13, Parts Drawing:
l Item 60 is changed to 62, and item 62 is changed
to 60.
Maximum fluid working pressure . . . . . . . . . . 100 psi (6.9 bar)
Maximum incoming air pressure . . . . . . . . . . 100 psi (6.9 bar)
Gun air consumption1 6
at 50 psi (0.45 at 3.5 bar)
Pump air consumption . . . . . . . . at 1 at 60 psi
(0.028 at 4.2 bar)
at free flow: 5.5 (0.15
Heater electrical requirement . . . . . . . . . . 2000 Watts, 110
16.7 Amp
Wetted parts
Pump* . acetal with conductive SST fibers, acetal, PTFE
Spray gun . . . . . . . . . . . . . . . . . . . . .
stainless steel
Fluid heater. . . . . . . . . . . . . . . . . . . . . . . . 304 stainless steel
Fluid hose and tubing . . . . . , . . . . . . . . . . . . . . . . , . . . . nylon
Fluid fittings . acetal,
stainless steel, carbon steel
Fluid regulator . . . . acetal resins, PTFE, tungsten carbide,
stainless steel
Fluid filter . . . . . . . . . . . . . . aluminum, carbon steel, PTFE,
stainless steel, polyethylene
l The male elbow (47) under the regulator (44)
is replaced with a m x f street elbow (25) and
a short nipple (66).
l
is not recommended for use with acid-catalyzed materials.
All 304, 316, and 17-4 stainless steels are
p a s s i v a t e d .
is a registered trademark of the DuPont Co.
The Warranty and Disclaimers
WARRANTY
warrants all equipment manufactured by it and bearing its name to be free from defects in material and workmanship on
the date of sale by an authorized distributor to the original purchaser for use. As purchaser’s sole remedy for breach of this
warranty, will, for a period of twelve months from the date of sale, repair or replace any part of the equipment proven
defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with
written recommendations.
This warranty does not cover, and shall not be liable for, any malfunction, damage or wear caused by faulty installation,
misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tamperfng, or substitution of
non-Grace component parts. Nor shall
be liable for malfunction, damage or wear caused by the incompatibility with
equipment of structures, accessories, equipment or materiais not supplied by or the improper design, manufacture,
installation, operation or maintenance of structures, accessories, equipment or materials not supplied by
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized distributor
for verification of the claim. If the claimed defect is verified, will repair or replace free of charge any defective parts. The
equipment will be returned to the transportation prepaid. If inspection of the equipment does not disclose any
defect in material or workmanship, will be made at a reasonable charge, which charges may include the costs of parts,
labor and transportation.
DISCLAIMERS AND LIMITATIONS
The terms of this warranty constitute purchaser’s sole and exclusive remedy and are in lieu of any other warranties (express or
implied), including warranty of merchantability or warranty of fitness for a particular purpose, and of any non-contractual
liabilities, including product liabilities, based on negligence or strict liability. Every form of liability for direct, special or
consequential damages or loss is expressly excluded and denied. In no case shall
liability exceed the amount of the
purchase price. Any action for breach of warranty must be brought within two (2) years of the date of sale.
EQUIPMENT NOT COVERED BY GRACO WARRANTY
makes no warranty, and disclaims all implied warranties of merchantability and fitness for a particular purpose, with
respect to accessories, equipment, materials, or components sold but not manufactured by These items sold, but not
manufactured by (such as electric motor, switches, hose, etc.) are subject to the warranty, if any, of their manufacturer.
will provide purchaser with reasonable assistance in making any claim for breach of these warranties.
Phone Number
TO PLACE AN ORDER, contact your distributor, or call this number to identify the distributor closest to you:
l-800-367-4023 Toll Free
Sales Offices: Atlanta, Chicago, Detroit, Los Angeles
Foreign Offices: Belgium, Canada, England, Korea, Switzerland, France, Germany, Hong Kong, Japan
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
PRINTED IN U.S.A. 308-448 September 1994, Revised December 1995
16 308-448
