Intel Pro/Wireless

Intel Pro/Wireless
2915ABG 802.11a/b/g

2915ABG 802.11a/b/g

2915ABG 802.11a/b/g
WLAN

WLAN

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802. 11g

Interoperability

Wi-Fi certified (details available at

http://www.hp.com/go/WLAN

)

Frequency Band

2.4 and 5 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12,18, 24, 36, 48, 54 Mbps

Modulation

Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM

Security

Supports 64- and 128-bit WEP, WPA, hardware-accelerated AES, 802.1x authentication
types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST. Support for
Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products
through the Cisco Compatible Extensions Program).

Sub-channels

Multinational support with frequency bands and channels compliant to local regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture

Network Architecture
Models

Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points.

Output Power

+16 dBm +/- 2dB'+16 dBm +/- 2dB (for CKK)
+15 dBm + 2 / -5 dB ((for OFDM; power varies by data rate)

Power Consumption

Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode: 100 mW, nominal

Power Management

ACPI compliant power management
802.11 Compliant Power Saving Mode

Receiver Sensitivity*

54 Mbps: -72 dBm, 11 Mbps: -89 dBm , 1 Mbps: -97 dBm

Antenna type

High efficiency dual band antenna with polarization diversity, mounted in the display
enclosure

Range

Range (typical)

802.11a - Typical

600 ft (82.88 m) at 1 Mbps - Outdoors Open Area
150 ft (45.72 m) at 1 Mbps - Indoor, Office-environment

802.11b - Typical

1200 ft (365.76 m)at 1 Mbps - Outdoors Open Area
300 ft (91.44 m) at 1 Mbps - Indoor, Office-environment
250 ft (76.2 m)at 54 Mbps - Indoor, Office-environment

802.11g - Typical

1200 ft (365.76 m) at 1 Mbps - Outdoors Open Area
300 ft (91.44 m) at 1 Mbps - Indoor, Office-environment
50 ft (15.24 m)at 54 Mbps - Indoor, Office-environment

Form Factor

MiniPCI Type IIIB

Weight

0.026 lb (11.75 gm) (max)

Dimensions

0.20 x 1.75 x 2.34 in (4.9 x 44.6 x 59.8 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating
Non-operating

32° to 176°F (0° to 80°C)
-40° to 176°F (-40° to 80°C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

Configuration Utility

Microsoft Windows XP Wireless Zero Configuration Utility
Intel PROset for Microsoft Windows 2000 or XP

LED Activity

LED Off – Radio OFF; Solid LED – Radio ON

*Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%
for 802.11a/g (OFDM modulation.
